Ring die is very important part of ring die pellet machine in the whole manufacturing process. The quality of ring die not only directly relates with the quality and output of pellets, but also the running state of equipment and maintenance cost.

Applicable for Biomass pellet machine: wood pellet mill, sawdust pellet mill, grass pellet mill, straw pellet mill, crop stalk pellet machine, alfalfa pellet mill etc.

Applicable for Fertilizer pellet machine, animal feed pellet machine too.

1. Material of the ring die:

Advantages of LYWF ring dies:

1. 20 years of experience in ring die production
2. High chromium high carbon content steels
3. Extremely precise manufacture
4. Advanced imported equipment
5. High hardness after heat treatment
6. Rapid delivery times
7. Test and control before shipment
8. Long service time

Compression Ratio of Ring Die

Generally speaking, the higher the compression ratio, the denser the finished pellets. But it does not mean that the higher the compression ratio, the better the pellet quality.
Compression ratio should be calculated based on raw material for making pellets and type of feed.
With many years pellet die manufacturing and research experience of WEIFENG Company, we provide some general data of ring die's compression ratio for your reference:

Buyers can customize dies with different hole diameter and compression ratio, according to different situation and requirement.

The most common structure of die hole are straight hole; release stepped hole; external conical hole and internal conical hole, etc. Different die holes structure are suitable for different raw material and feed formula for making pellets.
